Product Description
ETI 2' x 4' Daylight Harvesting LED Panel Troffer With Motion SensorDAYLIGHT HARVESTING FUNCTION A: When the natural light is sufficient or dark, movement is detected and the light will turn on and maintain to the foot candle level
DAYLIGHT HARVESTING FUNCTION B: Light turns on at full or dims to maintain the foot candle level. The light output regulates according to the level of natural light available
DAYLIGHT HARVESTING FUNCTION C: Light dims to stand-by period after 5 minutes (or 10 minutes) hold-time and stays on 30% of power level
DAYLIGHT HARVESTING FUNCTION D: Light switches off completely after 3 minutes (or 15 minutes ) stand-by period
DIP SWITCH SETTINGS (located on back of fixture): Position 1) Sensor Status, Position 2) Brightness Levels, 3) Detection Range, 4) Motion Hold and Stand-by Times *Details in Instruction Manual
MOTION SENSOR DETECTION COVERAGE: Height of installation 8-12ft. and distance senses at 100% at 34ft. and 50% at 17ft.
LUMEN BOOST LEVELS: 3300, 4400, 5500 Lumens
WATTAGE LEVELS: 30-Watt, 40-Watt, 50-Watt
COLOR TEMPERATURE OPTIONS: Neutral White 3500K, Bright White 4000K, Daylight 5000K
AC voltage, Frequency: 120-277 Volt, 60Hz
DIMMABLE - 0-10 Volt dimmer switch ONLY - Requires separate low-voltage wiring run - Suggested dimmers such as LUTRON: DVSTV-453PH-WH or DVELV-300PH-WH
Product Dimensions: 47.7in. L x 23.7in. W x 1.46 in. H - Weight: 8 lbs
Installation is standard recessed mount
Rated life up to 50,000 hours
MFG# 64209101
Ships from manufacturer. Please note that additional delivery time and freight charges may apply. Returns are not accepted.
Product Videos
Custom Field
Note Ships from manufacturer. Please note that additional delivery time and freight charges may apply. Returns are not accepted.
UNSPSC Code 39111544
MFG Part 64209101
