Mec Me1600D Series Dielectric Copper Pigtail, Pol X 1/4 In. Mnpt, Long

Product Description

ME1600D Series Dielectric pigtails/ hogtails are intended to isolate metallic piping from sources of electrical currentand to help prevent galvanic corrosion when used on underground containers. The ME1600D dielectric pigtail/ hogtail would typically be installed at the ASME tank directly upstream of the first stage regulator prior to underground piping, isolating the underground metallic piping from electric current. These pigtail and hogtail assemblies come with 2 brass connectors brazed onto a heavy wall annealed copper tube with a 250 psig pressure rating.1/4 MNPT x male hard nose pol, 7/8 nut1/4 tube ODLong nippleUL listed and tested in accordance with UL 569Dielectric protection12 in. L1/4 and 3/8 tube have a pull test rating of 500 and 750 lbs. respectively
